turbo charger 3775019 3775022 3790430 3790432

H300VG turbocharger 5327340 3775015 3790454 3795999 3775013 3775013NX 3775013RX 3775023 engine ISC ISL ISL9

Welcome to contact us :

Whatsapp / Wechat :+86 13606178432 Skype : jane.wang_15

QQ: 1127776325

Email:jane.wang@booshiwheel.com

Specification

Part Number	5327340
Previous Version	3775015, 3790454, 3795999, 3775013, 3775013NX, 3775013RX, 3775023, 3775023NX, 3775023RX, 3775031, 3775031NX, 3775031RX, 3775036, 3775036NX, 3775036RX, 3790431, 3790431NX, 3790431RX, 3790434, 3790434NX, 3790434RX, 3790443, 3790443NX, 3790443RX, 3790448, 3790448NX, 3790448RX, 3796066, 3796066NX, 3796066RX, 3796069, 3796069NX, 3796069RX, 3796078, 3796078NX, 3796078RX, 3796084, 3796084NX, 3796084RX
OE number	4352505, 4352506, 4352507, 4352510, 4352511, 4352515, 4352517 4309234, 4309234NX, 4309234RX, 4352506, 4352506NX, 4352506RX, 4352507, 4352507NX, 4352507RX, 4352508, 4352508NX, 4352508RX, 4352509, 4352509NX, 4352509RX, 4309244, 4309244NX, 4309244RX, 4309533, 4309533NX, 4309533RX, 4352505, 4352505NX, 4352505RX, 4352515, 4352515NX, 4352515RX, 4352516, 4352516NX, 4352516RX, 4352517, 4352517NX, 4352517RX, 4352518, 4352518RX, 4309244, 4309244NX, 4309244RX, 4309533, 4309533NX, 4309533RX, 4352505, 4352505NX, 4352505RX, 4352515, 4352515NX, 4352515RX, 4352516, 4352516NX, 4352516RX, 4352517, 4352517NX, 4352517RX, 4352518, 4352518RX
Year	2013-
Description	Truck, Various, Non-Transit Bus
Manufacturer Part Number	3775019, 3775022, 3790430, 3790432, 3790433, 3790435, 3796064, 3796065, 3796066, 3796067, 3796068, 3796069, 3796070, 3797404, 5327342, 5327343, 5327344, 5327345, 5327346, 5327347, 5327348, 5327349, 5324125, 5324125H, 5324125NX, 5324125RX, 5324130, 5324130NX, 5324130RX, 5326677, 5326677H, 5326677NX, 5326677RX, 5326680, 5326680NX, 5326680RX, 5327344, 5327344NX, 5327344RX, 5327347, 5327347NX, 5327347RX, 5328086, 5328086NX, 5328086RX, 5324116H, 5324121, 5324121NX, 5324121RX, 5324126, 5324126H, 5324126NX, 5324126RX, 5324131, 5324131NX, 5324131RX, 5326678, 5326678H, 5326678HX, 5326678NX, 5326678RX, 5326681, 5326681NX, 5326681RX, 5326684, 5326684H, 5326685, 532668500, 532668500H, 5326685H, 5327343, 5327343NX, 5327343RX, 5327345, 5327348, 5327348NX, 5327348RX, 5327349, 5328098, 5328099, 5328100, 5328101, 5328102, 5328103, 5328077, 5328087, 5328090, 5328090NX, 5328090RX, 5328097, 5328098, 5328099, 5329452H, 5501322, 796013
Turbo Model	H300VG, HE300VG, HE300
CHRA	N/A
Engine Manufacturer	Cummins
Engine	ISC, ISL, ISL9
Displacement	8.9L, 8900 ccm
Fuel	Diesel
Angle α (compressor housing)	155/183/257/270/285�
Angle β (turbine housing)	61/134/146/149.5�
Bearing Housing	3772968 (Water Cooled)
Turbine Wheel	3768300 (Ind. 59.95 mm, Exd. 69.7 mm, Trm 11.88, 12 Blades)(1154-300-435) NEW IN STOCK
Comp. Wheel	(28436675)(Ind. 54.3 mm, Exd. 86. mm, 7+7 Blades, Superback)
Back plate	3772261 NEW IN STOCK
Heat shield Number	NEW IN STOCK
Repair Kit	(Major)(1154400755) $120.81 NEW IN STOCK
Turbine Housing	37718915
Actuator Electronic	5494878 (3773938, 3773942, 3778619, 3778623, 3784299, 3784386, 3785180, 3788936, 4034090, 4034090NX, 4034168, 4034168NX, 4034309, 403430900, 403430900H, 403430900HX, 4034309H, 4034309HX, 4034309NX, 4034309RX, 4034394, 4034395, 4034395RX, 4633444, 5452689, 5459882, 549487800HX, 5494878H, 5494878HX, 5494878NX, 5494878RX, 5498269, 549826900H, 5498269H, 5498269NX, 5498269RX, 5579127, 557912700H, 557912700HX, 5579127H, 5579127HX, 5601240, 5601240H, 5601240HX, 5601240NX, 5601240RX, 68232771, 68232771AA, 68244609, 68244609AA, 68307025, 68307025AA, 68445522AA)(J1939-15, 03773941)(12 Volts) $1,206.90
NOTE	Restricted to OE customer
Turbine Housing AR	VGT
Manufacturer	Holset

Applications

2013- Cummins Truck, Various with ISC, ISL Engines
