3790665 3792227 4309470 4309471 430947000 430947100 4309471 430947100

HE300VG Turbo repair kit 5328296 5328084 3792225 430947100HX 4309471H 4309471NX 4309471RX 3792226 3792227 5328119 Turbo for Cummins Bus Truck with ISBE Engines

Welcome to contact us :

Whatsapp / Wechat :+86 13606178432 Skype : jane.wang_15

QQ: 1127776325

Email:jane.wang@booshiwheel.com

Specification

Part Number	3792225
Previous Version	3783027, 3786024, 3787273, 3789376, 3790665, 3792227
OE number	4309470, 4309471, 430947000, 430947100, 4309471, 430947100, 430947100HX, 4309471H, 4309471NX, 4309471RX
Year	2013-
Description	Cummins Bus, Truck, Various
Manufacturer Part Number	3792226, 3792227, 5328119, 5328119RX, 5328084, 5328084H, 5604741, 5604741H, 5604741HX, 5608235, 560823500
Turbo Model	H300VG, HE300VG, HE300
CHRA	N/A
Engine Manufacturer	Cummins
Engine	ISB/ISBE EURO 6
Displacement	6.7L, 6700 ccm
Fuel	Diesel
Angle α (compressor housing)	277/285°
Angle β (turbine housing)	85/295°
Bearing Housing	4048826 (Water Cooled)
Turbine Wheel	(Ind. 57. mm, Exd. 65. mm, Trm 8.39, 12 Blades)
Comp. Wheel	(Ind. 52. mm, Exd. 78. mm, Trm 4.19, 7+7 Blades, Superback)
Back plate	4046252 (4046253) $40.00 NEW IN STOCK
Heat shield Number	NEW IN STOCK
Repair Kit	(Major)(1154300755) $90.00 NEW IN STOCK
Nozzle Ring	3799839 $334.08 NEW IN STOCK
Turbine Housing AR	VGT
Speed Sensor	5327846 (04316352, 2837039, 2839964, 3777147, 4032316, 4044473, 4046015, 4046016, 4327174, 4327186, 4955360, 5462379, 5462383, 5550064, 904-7139, 9047139, DSE1210.20P20HZ, DSE1210.20P7HZ, DSE121020P20HZ, DSE121020P7HZ) $189.57
Electronic Actuator	5603456 (3778618, 3784300, 3785179, 3788935, 3788939, 4034089, 4034089NX, 4034089RX, 4034175, 4034175NX, 4034175RX, 4034308, 403430800H, 403430800HX, 4034308H, 4034308HX, 4034308NX, 4034308RX, 4034393, 4034393NX, 4034393RX, 4034398, 4034398NX, 4034398RX, 5452655, 5458935, 5458935NX, 5458935RX, 5496046, 549604600H, 549604600HX, 5496046H, 5496046HX, 5496046NX, 5496046RX, 5554033, 560345600H, 560345600HX, 5603456H, 5603456HX, 5603456NX, 5603456RX, 5603776, 5603776NX, 5603776RX)(24 Volts) $1,935.00
Gasket Set	4032553 (4032553, 403255300, 4032553H) $37.29
NOTE	This turbo is sold with the Electronic Actuator
Manufacturer	Holset

Applications

2013- Cummins Bus, Truck with ISBE Engines
