HX60M Turbocharger 3594608 3594608H 4027259 4027252 4027259H for cummins marine

HX60 Turbo 3800852 3592369 3592401 3800852 3800852NX 3800852RX 3592401 for Cummins Marine with QSM11 Engine

Welcome to contact us :

Whatsapp / Wechat :+86 13606178432 Skype : jane.wang_15

QQ: 1127776325

Email:jane.wang@booshiwheel.com

Specification

Part Number	3592369
Previous versions	3592401
OE number	3800852, 3800852NX, 3800852RX
Description	Marine
Manufacturer Part Number	3592401
CPL(s)	2443, 8363, 8753
CHRA	3594608 (3594608H, 4027259, 4027252, 4027259H) $1,241.34 IN STOCK
Turbo Model	HX60, HX60M, HX60-A1292C/B32JA1
Engine	M11, ISM CM570, ISM CM570/870, ISM CM875, ISM CM876, ISM CM876 E, ISM11 CM876 M103, ISM11 CM876 SN, M11 CELECT, M11 CELECT PLUS, M11 MECHANICAL, QSM11 CM570, QSM11 CM876
Engine Manufacturer	Cummins
Displacement	6 Cylinders
KW	635 HP
Fuel	Diesel
Angle α (compressor housing)	90º
Angle β (turbine housing)	30º
Bearing Housing	3536802 (353680200, 3536802H, 4038724)(Oil Cooled) $365.23 NEW IN STOCK
Turbine Wheel	3533025 (3533025H)(Ind. 97. mm, Exd. 86.3 mm, Trm 16.9, 12 Blades)(1153060435) $230.47 NEW IN STOCK
Comp. Wheel	3534650 (353465000)(Ind. 80. mm, Exd. 113. mm, Trm 9.25, 8+8 Blades, Superback) $269.00 NEW IN STOCK
Back plate	3531917 (1250403300) $67.06 NEW IN STOCK
Heat shield Number	3519155 (3758538, 18373, 351915500) $15.58 NEW IN STOCK
Repair Kit	4027881 (3545345, 3580568, 4027880)(1153060750) $125.00 NEW IN STOCK
Turbine Housing	3533986
Compressor Cover	3591396 $378.46
Gasket Kit	3545577 (468189-0000)(215082, 2090505397) $18.30 NEW IN STOCK
Gasket (oil outlet)	3519763 (129120, 210018-0000, 201048, 157602, 3037537)(1900000025) $4.38
Listed New	$3,391.52
Manufacturer	HOLSET

Applications

1999-06 Cummins Marine with QSM11 Engine
