HE400VG turbo 85141058, 85136171, 85136180, 85020012 for Mack, Volvo Truck, Various with MD13 Engine

HE431V 3791471 4031001 4031000 turbocharger 2008-15 Mack, Volvo FH13 Various Turbo

Welcome to contact us :

Whatsapp / Wechat :+86 13606178432 Skype : jane.wang_15

QQ: 1127776325

Email:jane.wang@booshiwheel.com

Specification

Part Number	3791471
Previous Version	2838751D, 4031001, 2838751, 3773437, 4048071, 4047375, 4047372, 3776436, 2835100, 2838751, 4046521, 3769175, 3780908, 4048071, 85136172, 85140458, 85141058, 85136171, 85136180, 85020012
OEM Customer	2838752, 3769189, 4046523, 4047376, 4047374, 3776441, 3776442, 2835102, 2838753, 3791497, 3791498, 3791484RV
OEM Supplied	21358882, 21595175, 21023370, 21178113, 21042279, 21675488, 21178112, 22014298, 22014299
Aftermarket	4031001, 4031000
Year	2008-15
Description	Truck Various Volvo FH13, Mack
Turbo Model	HE400VG, HE431Ve
CHRA	N/A
Engine	D13B, MD13, MD13 US07, MP7 EPA07, MP7 EPA10, MP8 EPA07, MP8 EPA07
Engine Manufacturer	Volvo
Displacement	13.0L 1300 ccm
KW	440/485 HP
Fuel	Diesel
Angle α (compressor housing	145/180/244°
Angle β (turbine housing)	166°
Bearing Housing	3791484
Turbine Wheel	(Ind. 59.53 mm, Exd. 74.71 mm, 11 Blades)
Compressor Wheel	785645 (Ind. 56.29 mm, Exd. 85.95 mm, 7+7 Blades, Superback)
Service Kit	$174.00 NEW IN STOCK
Actuator	85109211, 85140701
Gasket KIT	3545576 (201049, 3519763) $15.35
Replaces	3780908
Manufacturer	HOLSET

Applications

2008-15 Mack, Volvo Truck, Various with MD13 Engine
