  3. G30-770 G30 Ball Bearing Turbo 880693-5002S T3 Real Housing AR 0.83 with wastegate Turbocharger
G30-770 G30 Standard Rotation Ball Bearing turbo with wastegate T3 turbine

G30-770 G30 Ball Bearing Turbo 880693-5002S T3 Real Housing AR 0.83 with wastegate Turbocharger

Welcome to contact us :

Whatsapp / Wechat :+86 13606178432 Skype : jane.wang_15

QQ: 1127776325

Email:jane.wang@booshiwheel.com



Specification

G30-770 Compressor Turbine
Inducer Exducer Trim A/R Inducer Exducer Trim
HP: 475-770 Disp: 2.0L-3.5L 58mm 71mm 65 0.72 60mm 55mm 84
Turbo: Standard Rotation PN A/R Inlet Outlet Wastegate Divided
Assembled and calibrated with 0.5 bar actuator 880704-5005S 0.83 V-Band V-band Internal N
880704-5006S 1.01 V-Band V-band Internal N
Supercore PN
Standard Rotation 880693-5002S
Reverse Rotation 880694-5002S
Turbine Kits Standard Rotation PN A/R Inlet Outlet Wastegate Divided
  740902-0092 1.06 T4 V-Band Free Float Y
740902-0090 0.83 T3 V-Band Free Float N
740902-0091 1.01 T3 V-Band Free Float N
740902-0086 0.61 V-Band V-Band Free Float N
740902-0087 0.83 V-Band V-band Free Float N
740902-0088 1.01 V-Band V-band Free Float N
740902-0089 1.21 V-Band V-band Free Float N
740902-0094 0.83 V-Band V-band Internal N
740902-0095 1.01 V-Band V-band Internal N
Turbine Kits Reverse Rotation PN A/R Inlet Outlet Wastegate Divided
  740902-0100 0.83 T3 V-Band Free Float N
740902-0101 1.01 T3 V-Band Free Float N
740902-0096 0.61 V-Band V-Band Free Float N
740902-0097 0.83 V-Band V-band Free Float N
740902-0098 1.01 V-Band V-band Free Float N
740902-0099 1.21 V-Band V-band Free Float N
